Tricycle (Digital)

1.The main frame is welded with high-strength aluminum alloy round tubes, with a wall thickness of 2mm, and has the characteristics of high strength and light weight. The surface is treated by spraying and has the characteristics of anti- aging/corrosion resistance.

2. Foldable frame, foldable backrest, convenient for carrying and travel, and  can save space.

3. The seat cushion/back cushion is made of high-strength mesh fabric sewn  into shape, with a soft, breathable, non slip texture, smooth and beautiful  appearance. It is reinforced with a middle layer of canvas for reinforcement.  High tensile strength (the overall tensile strength of the seat cushion is up to  5000N).

4. Front wear-resistant 8-inch honeycomb tire, universal front wheel with  aluminum alloy opposite front fork, beautiful appearance; Rear 12 inch PU solid tire, wear-resistant and maintenance free.

5. The flip back armrest facilitates users to lift and lower the wheelchair from  the side, and the PU armrest pad provides better comfort.

6.250W wheel hub motor, intelligent controller, stop immediately upon release, safe, reliable, and powerful.

7. The feet are disassembled and flipped back for convenient transportation  and home storage;

8. This product is available in both manual and electric modes, making it  convenient for users to travel.

Total length 1000mm

Total width 700mm

Total height 940mm

Retract length 740mm

Folding width 470mm

Retract height 730mm

Seat width 460mm

Seat depth 400mm

Seat height above ground 510mm

Backrest height 400mm

Armrest height 215mm

Front wheel diameter 8 inches

Rear wheel diameter 12 inches

Frame material/pipe diameter * thickness 6061T4/φ 22 * 2T Motor 250W brushed motor

Motor power 250W/2 pieces

Lithium ion battery 10AH

Maximum range of 10km

Top speed 6km/h

Climbing ability ≥ 3 °

Obstacle crossing ability ≥ 25mm

Packaging size 780 * 450 * 790mm (outer size)

Net weight 24kg (including battery)

Carrying capacity 100kg
